Cooling  Btu

11600

Heating Btu

9500

Cooling  A

5.8

Heating A

4.24

Max. Input Power  W

/

Max. Input Current A

8

EER Cooling  W/W

2.7

COP Heating  W/W

2.9

Power supply source  V/Ph/Hz

220-240V~/50Hz

Refrigerant

R290

Refrigerant Charged  g

210

Air Flow Volume  m3/h

350

Noise Power dB（A)

62

Container Loading 20FT/40FT/40HC

92/200/341

CBM m3

0.209811375

Copper Tube  evaporator row

4

Copper Tube  evaporator pipe diameter mm

7-24U inner grooved copper

Copper Tube  condenser Row

4

Copper Tube  condenser pipe diameter mm

5-28U inner grooved copper

Fan motor (evaportor side)  Model

YDK18-6A

Fan motor (condensor side)  Model

YDK45-4

Compressor Model

DSM215

Brand

GMCC

Weight（Net )

34

Weight（Gross )

39

Net Dimension

476×385×710

Packing Dimension

545×435×885
